3M 9082

3M Ultra High Temperature Adhesive Transfer Tape 9082 is a clear 0.05 mm acrylic adhesive transfer tape with a 0.08 mm 55# densified-kraft release liner for thin, high-temperature bonding in electronics and automotive assemblies. The low-outgassing adhesive system retains measurable adhesion through elevated-temperature testing: 180 deg peel adhesion is 8.8 N/cm at 23 deg C and 5.3 N/cm at 177 deg C on aluminum-foil-backed specimens. Long-term temperature resistance is 177 deg C and short-term resistance is 280 deg C. The construction is intended for assemblies that combine thin bondlines with elevated processing or operating temperatures.

Key features

• High-temperature acrylic bonding: Long-term temperature resistance reaches 177 deg C, with short-term exposure resistance to 280 deg C.
• Low-outgassing thin transfer layer: The clear 0.05 mm adhesive layer provides a thin bonding profile for electronics and automotive assemblies.
• Measured elevated-temperature adhesion: Peel adhesion remains measurable through 230 deg C testing, with 5.3 N/cm recorded at 177 deg C.

Applications

Applications include automotive under-hood bonding, flexible printed circuit and FR-4 attachment, electronics and heat-sink bonding, and solder-reflow process assemblies.
