3M EC-2615
Harmonization Code : 3214.10.00 | Putty and other mastics | Resin cements, caulking compounds and other mastics
Main features
- Tough Impact Resistant Bonding
- High Shear And Peel Performance
- Non Sag Assembly Control
Product Description
3M Scotch-Weld Epoxy Adhesive EC-2615 B/A is a 100% solids, two-part non-sag epoxy for tough, impact-resistant bonds on prepared metal and selected plastic substrates. Mix Part B and Part A at 100:50 by volume; the off-white base and amber accelerator provide more than 20 minutes of work life for a 20 g batch at 22 deg C. After a seven-day room-temperature cure, prepared aluminum bonds reach 5500 psi overlap shear, 73 piw T-peel strength, and 98 piw floating-roller peel strength under the stated test conditions.
Key features
- Tough Impact Resistant Bond: The cured epoxy supports structural joints exposed to impact and service stress.
- High Shear And Peel Strength: Prepared metal assemblies benefit from strong shear and peel performance.
- Non Sag Application Control: Thixotropic consistency helps retain adhesive on vertical or irregular joints.
Applications
Structural bonding of prepared metal and selected plastic parts, including assemblies that need non-sag placement and impact resistance.
Technical Specifications
No specifications available.
Additional Information
As-supplied / before-processing properties
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Part B color | Off white | - | Before mixing |
| Part A color | Amber | - | Before mixing |
| Mix ratio by weight | 100:49 | B:A | Two-part system |
| Mix ratio by volume | 100:50 | B:A | Two-part system |
| Solids | 100 | % | Both components |
| Work life | More than 20 | min | 20 g mixed at 22 deg C |
After-processing / final-state properties
| Property | Value | Unit | Method / condition |
|---|---|---|---|
| Overlap shear strength | 5500 | psi | Aluminum; 7 day room-temperature cure; tested at 24 deg C |
| Conditioned overlap shear strength | 4400 | psi | Aluminum; 14 days at 71 deg C and 100% RH; tested at 24 deg C |
| T-peel strength | 73 | piw | Aluminum; ASTM D1876 at 24 deg C |
| Floating roller peel strength | 98 | piw | Aluminum; ASTM D3167 at 24 deg C |
